POWER SUNROOF — IF EQUIPPED
The power sunroof switch is located between the sun visors on the overhead console.
OPENING AND CLOSING THE SUNROOF
Push the switch rearward and release it within one-half second and the sunroof will open automatically from any position. The sunroof will open fully and stop automatically.
Push the switch forward and release it within one-half second and the sunroof will close automatically from any position. The sunroof will close fully and stop automatically.
During Express Open or Express Close operation, any other movement of the sunroof switch will stop the sunroof.
To open the sunroof, push and hold the switch rearward to full open.
To close the sunroof, push and hold the switch in the forward position.
Any release of the switch during open or close operation will stop the sunroof movement. The sunroof will remain in a partially opened position until the switch is operated and held again.
PINCH PROTECT FEATURE
This feature will detect an obstruction in the closing of the sunroof during the Express Close operation. If an obstruction in the path of the
sunroof is detected, the sunroof will 2
automatically retract. Remove the obstruction if
this occurs.
If three consecutive sunroof close attempts result in Pinch Protect reversals, Pinch Protect will disable and the sunroof must be closed in Manual Mode.
VENTING SUNROOF — EXPRESS
Push and release the Vent button within
one-half second and the sunroof will open to the vent position. This is called “Express Vent” and it will occur regardless of sunroof position.
During Express Vent operation, any movement of the switch will stop the sunroof.
SUNSHADE OPERATION
The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens.
The sunshade cannot be closed if the sunroof is open.
SUNROOF MAINTENANCE
Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. Periodically check for and clear out any debris that may have collected in the tracks.
