2022 Jeep Renegade Owners Manual - Uconnect Settings

When the Language button is pressed on the touchscreen, the system displays the different language options. Once an option is selected, the system will display in the chosen language. The available setting is:

Note:

Depending on the vehicle’s options, feature settings may vary.

Language

This setting will change the language of the Uconnect system and the Instrument Cluster Display. The available languages are English, Français, and Español.

When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the touchscreen. The available settings are:

Note:

Depending on the vehicle’s options, feature settings may vary.

Display Mode

This setting will allow you to set the brightness manually or have the system set it automatically. The “Auto” setting has the system automatically adjust the display brightness. The “Manual” setting will allow the user to adjust the brightness of the display.

Display Brightness With Headlights ON

This setting will allow you to set the brightness when the headlights are on. To access this setting, Display Mode must be set to Manual. The “+” setting will increase the brightness; the “-” will decrease the brightness.

Display Brightness With Headlights OFF

This setting will allow you to set the brightness when the headlights are off. To access this setting, Display Mode must be set to Manual. The “+” setting will increase the brightness; the “-” will decrease the brightness.

Set Theme

This setting will allow you to change the display theme.

Touchscreen Beep

This setting will allow you to turn the touchscreen beep on or off.

Control Screen Timeout

This setting will allow you to set the Control Screen to turn off automatically after five seconds or stay open until manually closed.

Navigation Next Turn Pop-ups Displayed in Cluster

This setting will display navigation prompts in the Instrument Cluster Display.

SiriusXM® Travel Link Weather Alerts

This setting will turn the weather alerts on or off.

When the Units button is pressed on the touchscreen, the system displays the different measurement options. The selected unit of measurement will display in the instrument cluster display and Navigation system (if equipped). The available settings are:

Note:

Depending on the vehicle’s options, feature settings may vary.

US

This setting will change the unit of measurement on the display to US.

Metric

This setting will change the unit of measurement on the display to Metric.

Custom

This setting will change the “Speed” (MPH or km/h), “Distance” (mi or km), “Fuel Consumption” (MPG [US], MPG [UK], L/100 km, or km/L), “Pressure” (psi, kPa, or bar), and “Temperature” (°C or °F) units of measurement independently.

When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature.

Note:

Depending on the vehicle’s options, feature settings may vary.

Voice Response Length

This setting will change the response length for the Voice Recognition system. The “Brief” setting provides a shortened audio description from the system. The “Detailed” setting provides the full audio description from the system.

Show Command List

This setting will allow you to turn the Command List on or off. The “Always” setting will always show the Command List. The “With Help” setting will show the Command List and provide a brief description of what the command does. The “Never” setting will turn the Command List off.

When the Clock & Date button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock.

Note:

Depending on the vehicle’s options, feature settings may vary.

Sync Time With GPS

This setting will sync the time to the GPS receiver in the system. The system will control the time via the GPS location.

Time Format

This setting will allow you to set the time format (AM/PM). Sync Time With GPS must be off for this setting to be available. The “12 hrs” setting will set the time to a 12-hour format. The “24 hrs” setting will set the time to a 24-hour format.

Set Time Hours

This setting will allow you to set the hours. Sync Time With GPS must be off for this setting to be available. The “+” setting will increase the hours. The “-” setting will decrease the hours.

Set Time Minutes

This setting will allow you to set the minutes. Sync Time With GPS must be off for this setting to be available. The “+” setting will increase the minutes. The “-” setting will decrease the minutes.

Show Time in Status Bar

This setting will place the time in the radio’s status bar.

Set Date in Cluster

This setting will allow you to set the day, month and year. Using “+” or “-”, you can scroll through the available days, months, or years.

When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features.

Note:

Depending on the vehicle’s options, feature settings may vary.

ParkView Backup Camera Delay

This setting will add a delay to the rear backup camera when shifting out of REVERSE.

Active ParkView Backup Camera Guidelines

This setting will turn the active backup camera guidelines on or off.

When the Safety/Driving Assistance button is pressed on the touchscreen, the system displays the options related to the vehicle’s safety settings. These options will differ depending on the features equipped on the vehicle. The settings may display in list form or within subfolders on the screen. To access a subfolder, select the desired folder; the available options related to that feature will then display on the screen.

Note:

Depending on the vehicle’s options, feature settings may vary.

Forward Collision Warning — Located In Automatic Emergency Braking Submenu

This setting will change the distance at which the Forward Collision Warning (FCW) alert sounds. The “Medium” setting will have the FCW system signal when an object is in view, and the possibility of a collision is detected. The “Near” setting will have the FCW system signal when the object is closer to the vehicle. The “Far” setting will have the FCW system signal when an object is at a far distance from the vehicle.

Forward Collision Sensitivity — Located In Automatic Emergency Braking Submenu

This setting will turn the Forward Collision Warning (FCW) system on or off. The “Off” setting will deactivate the FCW system. The “Warning Only” setting will provide only an audible chime when a collision is detected. The “Warning + Active Braking” setting will provide an audible chime and apply some brake pressure when a collision is detected.

LaneSense Warning

This setting will change the distance at which the steering wheel will provide lane departure feedback. The available settings are “Early”, “Medium”, and “Late”.

LaneSense Strength

This setting will change the strength of the steering wheel feedback during a lane departure. The available settings are “Low”, “Medium”, and “High”.

Side Distance Warning

This setting will adjust the warning for side distance. The available options are “Off”, “Sound Only”, and “Sound & Display”.

Side Distance Warning Volume

This setting will adjust the volume for side distance warning. The available options are “Low”, “Med”, and “High”.

Drowsy Driver Alert

This setting will monitor the driver’s driving habits and warn you of any changes, indicating that the driver may be drowsy. The available options are “On” and “Off”.

ParkSense

This setting will change the type of ParkSense alert when a close object is detected and can provide both an audible chime and a visual display.

Front ParkSense Volume

This setting will adjust the volume of the Front ParkSense system. The available settings are “Low”, “Medium”, and “High”.

Blind Spot Alert

This setting will change the type of alert provided when an object is detected in a vehicle’s blind spot. The “Off” setting will turn off Blind Spot Alert. The “Lights” setting will activate the Blind Spot Alert lights on the outside mirrors. The “Lights & Chime” setting will activate both the lights on the outside mirrors and an audible chime.

ParkView Backup Camera Active Guidelines

This setting will turn the ParkView Backup Camera Active Guidelines on or off.

When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the options related to the vehicle’s mirrors and wipers.

Note:

Depending on the vehicle’s options, feature settings may vary.

Rain Sensing Auto Wipers

This setting will turn the Rain Sensing Auto Wipers on or off.

Auto Folding Side Mirrors

This setting will automatically fold and unfold the side-view mirrors when the vehicle is turned on and off. The available options are “On” and “Off”.

Headlight Sensitivity

This setting will allow you to set the sensitivity of the headlights depending on the amount of visible light. The greater the sensitivity set, the less the external light variation required to turn on the lights (e.g. with a setting on level 3 at sunset, the headlights turn on earlier than in levels 1 and 2). The available levels are “Level 1: Minimum Sensitivity”, “Level 2: Medium Sensitivity”, and “Level 3: Maximum Sensitivity”.

After pressing the Brakes button on the touchscreen, the following settings will be available:

Note:

Depending on the vehicle’s options, feature settings may vary.

Auto Park Brake

This setting will turn the Auto Park Brake on or off.

Brake Service

This setting will allow you to set the brakes for service. When the setting is selected, a pop-up will display with “Yes” and “No” options.

When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights.

Note:

Interior Ambient Lighting

This setting will allow you to adjust the interior ambient lighting using “+” and “-” options.

Headlight Sensitivity

This setting will allow you to set the sensitivity of the headlights dependent on the amount of visible light. The greater the sensitivity set, the less the external light variation required to turn on the lights (e.g. with a setting on level 3 at sunset, the headlights turn on earlier than in levels 1 and 2). The available levels are “Level 1: Minimum Sensitivity”, “Level 2: Medium Sensitivity”, and “Level 3: Maximum Sensitivity”.

Headlight Off Delay

This setting will allow you to set the amount of time it takes for the headlights to shut off after the vehicle is unlocked. The available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

Daytime Running Lights

This setting will allow you to turn the Daytime Running Lights on or off.

Cornering Lights

When this setting is selected, if the steering wheel rotation angle is large or the turn signal indicators are on, a light (incorporated in the fog light) will turn on, on the relevant side to improve visibility at night.

Greeting Lights

When the “Greeting Lights” feature is selected, it allows the adjustment of the amount of time the headlights remain on after the doors are unlocked with the key fob. The available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

Auto Dim High Beams

This setting will allow you to turn the Auto Dim High Beams on or off.

Flash Lights with Lock

This setting will allow you to turn the flashing of the lights when the Lock button is pushed on the key fob on or off.

When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors.

Note:

Depending on the vehicle’s options, feature settings may vary.

Auto Door Locks

This setting will automatically lock your doors.

Auto Unlock On Exit

This setting will unlock the doors when any of the doors are opened from the inside.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock button is pushed on the key fob on or off.

Sound Horn With Lock

This setting will sound the horn when the Lock button is pushed on the key fob. The “Off” setting will not sound the horn when the Lock button is pushed. The “1st Press” setting will sound the horn when the Lock button is pushed once. The “2nd Press” setting will sound the horn when the Lock button is pushed twice.

Sound Horn With Remote Start

This setting will sound the horn when the remote start is activated from the key fob.

Passive Entry

This setting will allow you to turn the Passive Entry feature (Keyless Enter ‘n Go™) on or off.

1st Press Of Key Fob Unlocks

This setting will change how many pushes of the Unlock button on the key fob are needed to unlock all the doors. The “Driver Door” setting will only unlock the driver door on the first push on the Unlock button. The “All Doors” setting will unlock all doors with only one push of the Unlock button.

When the Seats & Comfort button is pressed on the touchscreen, the system displays the options related to the vehicle’s comfort systems when remote start has been activated or the vehicle has been started.

Note:

Depending on the vehicle’s options, feature settings may vary.

Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start

This setting will activate the vehicle’s comfort system and heated seats (if equipped) or heated steering wheel (if equipped) when the vehicle is remote started or ignition is started. The “Off” setting will not activate the comfort systems. The “Remote Start” setting will only activate the comfort systems when using Remote Start. The “All Start” setting will activate the comfort systems whenever the vehicle is started.

When the Key Off Options/Engine Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is set to OFF.

Note:

Depending on the vehicle’s options, feature settings may vary.

Radio Off Delay

This setting will keep the radio on for the selected amount of time after vehicle shut off. The available options are “0 sec” or “20 min”.

Radio Off With Door

This setting will shut the radio off when the door is opened. The available settings are “On” and “Off”.

Headlight Off Delay

This setting will allow you to set the amount of time it takes for the headlights to shut off after the vehicle is unlocked. The available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone.

Note:

Depending on the vehicle’s options, feature settings may vary.

Balance/Fade

This setting will adjust audio levels from specific speakers in the front/back and left/right of the vehicle. The Speaker icon can be moved to set audio location.

Equalizer

This setting will adjust the “Bass”, “Mid”, and “Treble” ranges of the audio.

Speed Adjusted Volume

This setting will adjust audio volume as speeds increase. At a higher setting, the volume will increase more as the vehicle speeds up. The available settings are “Off”, “1”, “2”, and “3”.

Surround Sound

This setting will turn the Surround Sound system on or off.

AUX Volume Offset

This setting will tune the audio levels from a device connected through the AUX port. The available settings are “+” and “-”.

Auto Play

This setting will automatically begin playing audio from a connected device.

Loudness

This setting will improve audio quality at lower volumes.

Auto-On Radio

This setting will automatically turn the radio on when the vehicle is started. The available settings are “Off”, “On”, and “Recall Last”. With Recall Last, the system resumes the previous task before vehicle shut off.

When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu.

Note:

Depending on the vehicle’s options, feature settings may vary.

Phone Pop-Ups Displayed In Cluster

This setting will activate phone message pop-ups in the Instrument Cluster Display.

Do Not Disturb

This setting will open the Do Not Disturb settings menu. The settings are “Auto Reply” (both, text, call), “Auto Reply Message” (custom, default), and “Custom Auto Reply Message” (create message).

Paired Phones

This setting will show the list of paired phones.

Paired Phones And Audio Devices

This setting will show the list of paired phones and audio devices.

Projection Manager

This setting will activate your smartphone to project on the vehicle’s touchscreen.

When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® Satellite Radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning.

Note:

Tune Start

This setting will play the current song from the beginning when you tune to a music channel using one of the 12 presets.

Channel Skip

This setting will allow you to set channels that you wish to skip. A channel list will display of the skipped channels.

Subscription Information

This menu provides SiriusXM® subscription information. SiriusXM® Travel Link is a separate subscription.

When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can clear personal data and reset selected settings from other menus.

Note:

Depending on the vehicle’s options, feature settings may vary.

Restore Settings/Restore Settings to Default

This setting will return all the previously changed settings to their factory defaults.

Restore Apps

This setting will reset the apps to their factory defaults.

Reset Apps Drawer To Default Order

This setting will return the apps drawer to the default order. The available options are “Yes” and “Cancel”. The X button can also be pressed to cancel the screen.

Clear Personal Data

This setting will display a pop-up that gives you the option to clear all personal data from the system, including Bluetooth® devices and presets.
