2019 GMC Sierra 1500 Owners Manual - Vehicle Data

Application

Capacities

Metric

English

Air Conditioning Refrigerant

For the air conditioning system refrigerant type and charge amount, see the refrigerant label under the hood. See your dealer for more information.

Cooling System

2.7L L4 1500 Series

11.8 L

12.5 qt

4.3L V6 1500 Series

11.6 L

12.3 qt

5.3L V8 1500 Series (L82)

12.4 L

13.1 qt

5.3L V8 1500 Series (L84)

12.6 L

13.3 qt

6.2L V8 1500 Series

13.1 L

13.8 qt

Engine Oil with Filter

2.7L L4 1500 Series

5.7 L

6.0 qt

4.3L V6 1500 Series

5.7 L

6.0 qt

Application

Capacities

Metric

English

5.3L V8; 6.2L V8 1500 Series

7.6 L

8.0 qt

Fuel Tank

1500 Series Standard and Short Box (Gas & 4WD Diesel)

90.9 L

24.0 gal

1500 Series Standard and Short Box (2WD Diesel)

83.3 L

22.0 gal

1500 Series Long Box

106.0 L

28.0 gal

Transfer Case Fluid

1.5 L

1.6 qt

Wheel Nut Torque

190 Y

140 lb ft

All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual. Recheck fluid level after filling.

Engine

VIN Code

Spark Plug Gap

2.7L L4 (L3B)

K

0.65–0.75 mm (0.026–0.030 in)

4.3L V6 (LV3)

H

0.95–1.10 mm (0.037–0.043 in)

5.3L V8 (L82)

F

0.95–1.10 mm (0.037–0.043 in)

5.3L V8 (L84)

D

0.95–1.10 mm (0.037–0.043 in)

6.2L V8 (L87)

L

0.95–1.10 mm (0.037–0.043 in)
