Symbol glossary
Some car components have colored labels with symbols indicating precautions to be observed when using this component. It is important to follow all warnings when operating your vehicle. See below for the definition of each symbol WARNING LIGHTS AND MESSAGES.
Note:
Warning and Indicator lights are different based upon equipment options and current vehicle status. Some telltales are optional and may not appear.
|
|
Red Warning Lights |
 |
Air Bag Warning Light Air Bag Warning Light |
 |
Brake Warning Light Brake Warning Light |
 |
Battery Charge Warning Light Battery Charge Warning Light |
 |
Door Open Warning Light Door Open Warning Light |
 |
Electric Power Steering (EPS) Fault Warning Light Electric Power Steering (EPS) Fault Warning Light |
 |
Electronic Throttle Control (ETC) Warning Light Electronic Throttle Control (ETC) Warning Light |
 |
Engine Coolant Temperature Warning Light Engine Coolant Temperature Warning Light |
 |
Oil Pressure Warning Light Oil Pressure Warning Light |
 |
Oil Temperature Warning Light Oil Temperature Warning Light |
 |
Seat Belt Reminder Warning Light Seat Belt Reminder Warning Light |
 |
Transmission Temperature Warning Light Transmission Temperature Warning Light |
 |
Trunk Open Warning Light Trunk Open Warning Light |
 |
Vehicle Security Warning Light Vehicle Security Warning Light — If Equipped |
|
|
Yellow Warning Lights |
 |
Anti-Lock Brake System (ABS) Warning Light Anti-Lock Brake System (ABS) Warning Light |
 |
Engine Check/Malfunction Indicator Warning Light (MIL) Engine Check/Malfunction Indicator Warning Light (MIL) |
 |
Electronic Stability Control (ESC) Active Warning Light Electronic Stability Control (ESC) Active Warning Light — If Equipped |
 |
Electronic Stability Control (ESC) OFF Warning Light Electronic Stability Control (ESC) OFF Warning Light — If Equipped |
 |
LaneSense Warning Light LaneSense Warning Light — If Equipped |
 |
Low Fuel Warning Light Low Fuel Warning Light |
 |
Service Forward Collision Warning (FCW) Light Service Forward Collision Warning (FCW) Light — If Equipped |
 |
Service LaneSense Warning Light Service LaneSense Warning Light — If Equipped |
 |
Service Adaptive Cruise Control (ACC) Warning Light Service Adaptive Cruise Control (ACC) Warning Light — If Equipped |
 |
Tire Pressure Monitoring System (TPMS) Warning Light Tire Pressure Monitoring System (TPMS) Warning Light |
|
|
Yellow Indicator Lights |
 |
Forward Collision Warning (FCW) OFF Indicator Light Forward Collision Warning (FCW) OFF Indicator Light — If Equipped |
|
|
Green Indicator Lights |
 |
Adaptive Cruise Control (ACC) Set Without Target Vehicle Indicator Light Adaptive Cruise Control (ACC) Set Without Target Vehicle Indicator Light — If Equipped |
 |
Adaptive Cruise Control (ACC) Set With Target Vehicle Indicator Light Adaptive Cruise Control (ACC) Set With Target Vehicle Indicator Light — If Equipped |
 |
Cruise Control Set Indicator Light Cruise Control Set Indicator Light — If Equipped |
 |
ECO Mode Indicator Light ECO Mode Indicator Light — If Equipped |
 |
Front Fog Indicator Light Front Fog Indicator Light — If Equipped |
|
LaneSense Indicator Light LaneSense Indicator Light — If Equipped |
 |
Parking/Headlights On Indicator Light Parking/Headlights On Indicator Light |
 |
Turn Signal Indicator Lights Turn Signal Indicator Lights |
|
|
White Indicator Lights |
|
Adaptive Cruise Control (ACC) Ready Indicator Light Adaptive Cruise Control (ACC) Ready Indicator Light — If Equipped |
 |
Cruise Control Ready Indicator Light Cruise Control Ready Indicator Light |
|
LaneSense Indicator Light LaneSense Indicator Light — If Equipped |
|
|
Blue Indicator Lights |
 |
High Beam Indicator Light High Beam Indicator Light |
