Symbol Glossary
Some car components have colored labels with symbols indicating precautions to be observed when using this component. It is important to follow all warnings when operating your vehicle. See below for the definition of each symbol .
Note:
Warning and Indicator lights are different based upon equipment options and current vehicle status. Some telltales are optional and may not appear.
|
Red Warning Lights |
|
 |
Air Bag Warning Light |
 |
Brake Warning Light |
 |
Battery Charge Warning Light |
 |
Door Open Warning Light |
 |
Drowsy Driver Detected Warning Light |
 |
Electric Power Steering (EPS) Fault Warning Light |
 |
Electronic Throttle Control (ETC) Warning Light |
 |
Engine Coolant Temperature Warning Light |
 |
Hood Open Warning Light |
 |
Liftgate Open Warning Light |
 |
Night Vision Animal Warning Light |
 |
Night Vision Pedestrian Warning Light |
 |
Oil Pressure Warning Light |
 |
Oil Temperature Warning Light |
 |
Seat Belt Reminder Warning Light |
 |
Transmission Temperature Warning Light |
 |
Vehicle Security Warning Light |
 |
Active Driving Assist - Driver Inattentiveness Warning Light |
|
Yellow Warning Lights |
|
 |
Anti-Lock Brake System (ABS) Warning Light |
 |
Drowsy Driver Detected System Fault Warning Light |
 |
Electric Park Brake Warning Light |
 |
Electronic Stability Control (ESC) Active Warning Light |
 |
Electronic Stability Control (ESC) OFF Warning Light |
 |
Service Active Lane Management Warning Light |
 |
Active Lane Management Warning Light |
 |
Low Fuel Warning Light |
 |
Low Washer Fluid Warning Light |
|
Night Vision Animal Warning Light |
|
Night Vision Pedestrian Warning Light |
 |
Engine Check/Malfunction Indicator Warning Light (MIL) |
 |
Service 4WD Warning Light |
 |
Service Adaptive Cruise Control (ACC) Warning Light |
 |
Service Forward Collision Warning (FCW) Or Pedestrian Emergency Braking (PEB) Light |
 |
Service Stop/Start System Warning Light |
 |
Tire Pressure Monitoring System (TPMS) Warning Light |
 |
Sway Bar Fault Warning Light |
|
Active Driving Assist - Driver Inattentiveness Warning Light |
 |
Active Driving Assist Fault Warning Light |
 |
Air Suspension Fault Warning Light |
|
Yellow Indicator Lights |
|
 |
Sway Bar Indicator Light |
 |
4WD Low Indicator Light |
 |
Air Suspension Active Indicator Light |
 |
Max Payload Exceeded Indicator Light |
 |
Air Suspension Aerodynamic Height Indicator Light |
 |
Air Suspension Entry/Exit Indicator Light |
 |
Air Suspension Off-Road 1 Indicator Light |
 |
Air Suspension Off-Road 2 Indicator Light |
 |
Auto HOLD! Fault Indicator Light |
 |
Forward Collision Warning (FCW) Or Pedestrian Emergency Braking (PEB) OFF Indicator Light |
 |
NEUTRAL Indicator Light |
|
Green Indicator Lights |
|
 |
Adaptive Cruise Control (ACC) Set With Target Light |
 |
Adaptive Cruise Control (ACC) Set With No Target Detected Indicator Light |
 |
Auto HOLD Indicator Light |
 |
Cruise Control SET Indicator Light |
 |
Front Fog Indicator Light |
|
Active Lane Management Indicator Light |
 |
Night Vision Active Indicator Light |
 |
Parking/Headlights On Indicator Light |
 |
Sport Mode Indicator Light |
 |
Stop/Start Active Indicator Light |
 |
Turn Signal Indicator Lights |
|
Active Driving Assist - Driver Attentive Indicator Light |
|
White Indicator Lights |
|
|
Adaptive Cruise Control (ACC) Ready Indicator Light |
 |
Cruise Control Ready Indicator Light |
 |
Hill Descent Control (HDC) Indicator Light |
 |
Rear Seat Unoccupied Indicator Light |
 |
Selec-Speed Control Indicator Light |
|
Active Driving Assist On Indicator Light |
|
Blue Indicator Lights |
|
 |
High Beam Indicator Light |
|
Gray Indicator Lights |
|
|
Night Vision Suppressed Indicator Light |
Download Manual
