HomeLink® Universal Transceiver*

The HomeLink® Universal Transceiver can be programmed to operate up to three remote controlled devices around your home, such as garage doors, lighting, or home security systems.

Important Safety Precautions Refer to the safety information that came with your garage door opener to test that the safety features are functioning properly. If you do not have the safety

information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

Not available on all models

uuHomeLink® Universal Transceiver*uTraining HomeLink

If it is necessary to erase a previously entered learned code:

Press and hold the I and III HomeLink buttons for about 10 seconds, until the green indicator blinks. Release the buttons, and proceed to step 1.

If you are training the second or third button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but may not work for all. For detailed instructions about your specific remote opener, visit http://www.homelink.com or call (800) 355-3515.

Continued

uuHomeLink® Universal Transceiver*uTraining HomeLink

Programming a Button

YES

3a. Hold the button on the remote transmitter. Does HomeLink indicator (LED) change from slowly flashing orange to rapidly flashing green or continuously on green? The process should take less than 60 seconds.

Press and hold the programmed HomeLink button for about a second. Does the device (garage door opener) work?

NO

3b. Canadian Garage Door Opener

A. Press and release the HomeLink button. Press, hold and release the button on the remote every 2 secs. Does the HomeLink indicator (LED) change from slowly flashing orange to rapidly flashing or continuously on green? The process should take less than 60 seconds.

YES NO

Models with color audio system

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using your vehicle’s audio system, without handling your cell phone.

HFL Buttons

Continued

uuBluetooth® HandsFreeLink® uUsing HFL

(Pick-up) button: Press to go directly to the Phone screen or to answer an incoming call.

(Hang-up/back) button: Press to end a call or to cancel a command.

(Talk) button: Press to call a number with a stored voice tag.

(Phone) button: Press to go directly to the Phone screen.

Selector knob: Rotate to select an item on the screen, then press .

uuBluetooth® HandsFreeLink® uUsing HFL

HFL Status Display

The audio/information screen notifies you when there is an incoming call.

Limitations for Manual Operation Certain manual functions are disabled or inoperable while the vehicle is in motion. You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored speed dial entries can be called using voice commands while the vehicle is in motion.

2 Speed Dial P. 384

uuBluetooth® HandsFreeLink® uHFL Menus

The ignition switch must be in ACCESSORY q or ON w to use HFL.

or

Phone Speed Dial*1 Add New

Call History

Select a phone number from the call history to store as a speed dial number.

Call History*1

(Existing entry list)

Dialed Calls

Received Calls

Missed Calls

Select a phone number from the phonebook to store as a speed dial number.

Phone Number Enter a phone number to store as a speed dial Display the last 20 outgoing calls.

Display the last 20 incoming calls.

Display the last 20 missed calls.

Phonebook*1

Dial*1

Display the paired phones’s phonebook.

Enter a phone number to dial.

*1 : Appears only when a phone is connected to HFL.

uuBluetooth® HandsFreeLink®uHFL Menus

Redial*1 Redial the last number dialed in the phone’s history.

Phone Setup

Bluetooth Setup

Add New Device

Connect a Phone

Pair a phone to the system.

Connect a phone to the system.

Connect an Audio Device

Connect a Bluetooth® Audio device to the system.

Disconnect All Devices

Delete Device

Disconnect a paired phone from the system.

Delete a previously paired phone.

Pass-key Create a code for a paired phone.

*1: Appears only when a phone is connected to HFL.

Continued

371

uuBluetooth® HandsFreeLink® uHFL Menus

Select a phone number from the call history to store as a speed dial number.

Select a phone number from the phonebook to store as a speed dial number.

Enter a phone number to store as a speed dial number.

Change a previously stored speed dial number.

Delete a previously stored speed dial number.

Create a voice tag for a speed dial number.

Change a voice tag for a speed dial number.

*1 : Appears only when a phone is connected to HFL.

Delete a voice tag for a speed dial number.

uuBluetooth® HandsFreeLink®uHFL Menus

Set calls to automatically transfer from your phone to HFL when you enter the vehicle.

Ringtone

Mobile Phone

Select the ring tone stored in the connected cell phone.

Fixed Select the ring tone stored in HFL.

Caller ID Info

Name Priority

Prioritize the caller’s name as the caller ID.

Number Priority

Prioritize the caller’s phone number as the caller ID.

System Clear

Clear the system of all paired phones, phonebook entries, and security codes.

Continued

373

uuBluetooth® HandsFreeLink® uHFL Menus

■  Phone Setup

Press the button or the button.

Make sure your phone is in search or discoverable mode.

Rotate to select Yes, then press .

u The audio system will enter a waiting mode for pairing.

Select HandsFreeLink from your phone.

u If you want to pair a phone from this audio system, press and follow the prompts.

When your phone appears on the list, select it by pressing .

The system gives you a pairing code on the audio/information screen.

u Confirm if the pairing code on the screen and your phone match.

This may vary by phone.

A notification appears on the screen if pairing is successful.

374

uuBluetooth® HandsFreeLink®uHFL Menus

To pair a cell phone (when a phone has already been paired to the system)

Press the button or the button.

u If a prompt appears asking to connect to a phone, select No and proceed with step 2.

Rotate to select Phone Setup, then press .

Rotate to select Bluetooth Setup, then press .

Rotate to select Add New Device, then press .

u The screen changes to a device list.

Continued

375

uuBluetooth® HandsFreeLink® uHFL Menus

Make sure your phone is in search or discoverable mode, then press .

u HFL automatically searches for a

Bluetooth® device.

When your phone appears on the list, select it by pressing .

u If your phone does not appear, select Phone Not Found? and search for Bluetooth® devices using your phone. From your phone, select HandsFreeLink.

The system gives you a pairing code on the audio/information screen.

u Confirm if the pairing code on the screen and your phone match.

This may vary by phone.

uuBluetooth® HandsFreeLink®uHFL Menus

To change the currently paired phone

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Bluetooth Setup, then press .

Rotate to select Connect a Phone, then press .

u The screen changes to a device list.

Rotate to select a desired device name, then press .

u HFL disconnects the connected phone and starts searching for another paired phone.

Continued

377

uuBluetooth® HandsFreeLink® uHFL Menus

To change the pairing code setting

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Bluetooth Setup, then press .

Rotate to select Pass-Key, then press .

Input a new pairing code, then press .

uuBluetooth® HandsFreeLink®uHFL Menus

To delete a paired phone

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Bluetooth Setup, then press .

Rotate to select Delete Device, then press .

u The screen changes to a device list.

Rotate to select a phone you want to delete, then press .

A confirmation message appears on the screen. Rotate to select Yes, then press .

Continued

379

uuBluetooth® HandsFreeLink® uHFL Menus

■  Automatic Transferring If paring between your phone and the system is executed while you are on the phone, the call can be automatically transferred to HFL.

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Auto Transfer, then press .

Rotate to select On or Off, then press .

uuBluetooth® HandsFreeLink®uHFL Menus

You can change the ring tone setting.

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Ringtone, then press .

Rotate to select Fixed or Mobile Phone, then press .

■  Caller’s ID Information You can select a caller’s information to be displayed when you have an incoming call.

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Caller ID Info, then press .

Rotate to select a mode you want, then press .

Continued 381

uuBluetooth® HandsFreeLink® uHFL Menus

■  To Clear the System Pairing codes, paired phones, all stored voice tags, all speed dial entries, all call history data, and all imported phonebook data are erased.

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select System Clear, then press .

Rotate to select Yes, then press .

A confirmation message appears on the screen. Rotate to select Yes, then press .

A notification appears on the screen. Press .

uuBluetooth® HandsFreeLink®uHFL Menus

■  Automatic Import of Cellular Phonebook and Call History When your phone is paired, the contents of its phonebook and call history are automatically imported to HFL.

Continued 383

uuBluetooth® HandsFreeLink® uHFL Menus

Up to 20 speed dial numbers can be stored per phone.

To store a speed dial number:

Press the button or the button.

Rotate to select Speed Dial, then press .

Rotate to select Add New, then press .

Rotate to select a place to choose a number from, then press .

From Call History:

u Select a number from the call history. From Phonebook:

u Select a number from the connected cell phone’s imported phonebook.

From Phone Number:

u Input the number manually.

When the speed dial is successfully stored, you are asked to create a voice tag for the number. Rotate to select Yes or No, then press .

Using the button, follow the prompts to say the name for the speed dial entry.

uuBluetooth® HandsFreeLink®uHFL Menus

To edit a speed dial

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Speed Dial, then press .

Select an existing speed dial entry.

Rotate to select Change Speed Dial, then press .

Select a new speed dial number, then press .

Continued

385

uuBluetooth® HandsFreeLink® uHFL Menus

To add a voice tag to a stored speed dial number

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Speed Dial, then press .

Select an existing speed dial entry.

Rotate to select Store Voice Tag, then press .

Using the button, follow the prompts to complete the voice tag.

To change a voice tag

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Speed Dial, then press .

Select an existing speed dial entry.

Rotate to select Change Voice Tag, then press .

Using the button, follow the prompts to complete the voice tag.

uuBluetooth® HandsFreeLink®uHFL Menus

To delete a voice tag

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Speed Dial, then press .

Select an existing speed dial entry.

Rotate to select Delete Voice Tag, then press .

u A confirmation message appears on the screen. Rotate to select Yes, then press .

To delete a speed dial number

Press the button or the button.

Rotate to select Phone Setup, then press .

Rotate to select Speed Dial, then press .

Select an existing speed dial entry.

Rotate to select Delete Speed Dial, then press .

u A confirmation message appears on the screen. Rotate to select Yes, then press .

Continued

uuBluetooth® HandsFreeLink® uHFL Menus

■  Making a Call You can make calls by inputting any phone number, or by using the imported phonebook, call history, speed dial entries, or redial.

uuBluetooth® HandsFreeLink®uHFL Menus

To make a call using the imported phonebook

When your phone is paired, the contents of its phonebook are automatically imported to HFL.

Press the button or the button.

Rotate to select Phonebook, then press .

The phonebook is stored alphabetically. Rotate to select the initial, then press .

Rotate to select a name, then press .

Rotate to select a number, then press .

u Dialing starts automatically.

To make a call using a phone number

Press the button or the button.

Rotate to select Dial, then press .

Rotate to select a number, then press .

Rotate to select , then press .

u Dialing starts automatically.

Continued 389

uuBluetooth® HandsFreeLink® uHFL Menus

To make a call using redial

Press the button or the button.

Rotate to select Redial, then press .

u Dialing starts automatically.

To make a call using the call history Call history is stored by Dialed Calls, Received Calls, and Missed Calls.

Press the button or the button.

Rotate to select Call History, then press .

Rotate to select Dialed Calls, Received Calls, or Missed Calls, then press .

Rotate to select a number, then press .

u Dialing starts automatically.

uuBluetooth® HandsFreeLink®uHFL Menus

To make a call using a speed dial entry

Press the button or the button.

Rotate to select Speed Dial, then press .

Rotate to select a number, then press .

u Dialing starts automatically.

Continued 391

uuBluetooth® HandsFreeLink® uHFL Menus

When there is an incoming call, an audible notification sounds and the Incoming Call screen appears.

Press the button to answer the call.

Press the button to decline or end the call.

uuBluetooth® HandsFreeLink®uHFL Menus

The following options are available during a call.

Swap Call: Put the current call on hold to answer the incoming call.

Mute: Mute your voice.

Transfer Call: Transfer a call from HFL to your phone.

Dial Tones: Send numbers during a call. This is useful when you call a menu-driven phone system.

To view the available options, press the button.

Rotate to select the option, then press .

u The check box is checked when Mute is selected. Select Mute again to turn it off.
