Gauges and Driver Information Interface
Gauges include the speedometer, tachometer, fuel gauge, and related indicators.
They are displayed when the ignition switch is in ON w*1.
Displays your driving speed in mph or km/h.
Shows the number of engine revolutions per minute.
Displays the amount of fuel left in the fuel tank.
Displays the temperature of the engine coolant.
*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.
Continued
111
uuGauges and Driver Information InterfaceuGauges
Blinks when the tachometer reading approaches the red zone.
* Not available on all models
uuGauges and Driver Information Interface uDriver Information Interface
The driver information interface displays the odometer, trip meter, outside temperature, and other gauges.
It also displays important messages such as warnings and other helpful information.
Continued
uuGauges and Driver Information InterfaceuDriver Information Interface
Press the (display/information) button and press
or
to change the display. Press ENTER to see detailed information.
*1:You can add the contents using the audio/information screen.
114
uuGauges and Driver Information Interface uDriver Information Interface
*1:You can add the contents using the audio/information screen.
* Not available on all models
Continued
115
uuGauges and Driver Information InterfaceuDriver Information Interface
116
Shows the total number of miles or kilometers that your vehicle has accumulated.
Shows the total number of miles or kilometers driven since the last reset. Meters A and B can be used to measure two separate trips.
To reset a trip meter, display it, then press and hold the
knob. The trip meter is reset to 0.0.
uuGauges and Driver Information Interface uDriver Information Interface
economy is also reset.
Shows the time elapsed since Trip A or Trip B was reset.
Shows the average speed in mph or km/h since Trip A or Trip B was reset.
Shows the remaining oil life and Maintenance MinderTM.
2 Maintenance MinderTM P. 551
* Not available on all models
Continued 117
uuGauges and Driver Information InterfaceuDriver Information Interface
Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).
Adjust the temperature reading by up to ±5°F or ±3°C if the temperature reading seems incorrect.
Use the customized features in the driver information interface or audio/information screen to correct the temperature.
2 Customized Features P. 124, 337
Shows the instant fuel economy as a bar graph in mpg or l/100 km.
When the turbo charger is producing boost, this meter shows the boost pressure.
uuGauges and Driver Information Interface uDriver Information Interface
Models with Display Audio
Display Audio shows you turn-by-turn directions to your destination.
Models with navigation system
When the navigation system is not providing driving guidance, an image of a compass appears in the driver information interface.
2 Refer to the Navigation System Manual
Shows the current audio information.
2 Audio System Basic Operation P. 239
Shows the current mail information.
2 Bluetooth® HandsFreeLink® P. 394
Shows the current phone information.
2 Bluetooth® HandsFreeLink® P. 394
Continued 119
uuGauges and Driver Information InterfaceuDriver Information Interface
Displays the strength (G) and direction of the load that is applied to the vehicle during driving.
Displays the brake pressure in psi when the brake is applied.
Displays the accelerator position in degrees of
%.
* Not available on all models
uuGauges and Driver Information Interface uDriver Information Interface
Light up from left to right according to engine speed.
* Not available on all models
Continued
121
uuGauges and Driver Information InterfaceuDriver Information Interface
Measures the lap time, and displays the previously measured times, split time and the fastest lap time.
u To measure the time per lap, press the 3 / 4 button at the completion of each lap.
u To return to the Stopwatch screen, press the (Hang-up/back) button.
* Not available on all models
uuGauges and Driver Information Interface uDriver Information Interface
button (when lap time is not running) to change the display, then press the 3 / 4 button to scroll through lap times.u A maximum of 20 lap times can be stored at a time.
button.Continued
123
uuGauges and Driver Information InterfaceuDriver Information Interface
Models with color audio system
Use the driver information interface to customize certain features.
Select the Vehicle Settings screen by pressing the button while the ignition switch is in ON w, and the vehicle is at a complete stop, and the shift lever is in
(continuously variable transmission), and the parking brake is set (manual transmission). Select Vehicle Settings, then press the ENTER button.
124
uuGauges and Driver Information Interface uDriver Information Interface
Press the button.
Forward Collision Warning Distance
ACC Forward Vehicle Detect Beep
Road Departure Mitigation Setting
Lane Keeping Assist Suspend Beep
Language Selection
Adjust Outside Temp. Display
Tachometer
* Not available on all models
Continued
125
uuGauges and Driver Information InterfaceuDriver Information Interface
Interior Light Dimming Time Headlight Auto OFF Timer
Auto Light Sensitivity*
Auto Interior Illumination Sensitivity*
Maintenance Info.
Auto Door Lock
Auto Door Unlock
Key And Remote Unlock Mode Keyless Lock Answer Back
Security Relock Timer
Default All
126
* Not available on all models
uuGauges and Driver Information Interface uDriver Information Interface
Setup Group Customizable Features Description Selectable Settings
ACC Forward Vehicle
Changes at which distance the CMBSTM alerts. Long/Normal*1/Short
Causes the system to beep when the system detects
Detect Beep
Road Departure Mitigation Setting
Lane Keeping Assist Suspend Beep
a vehicle, or when the vehicle goes out of ACC range.
Changes the setting for the road departure mitigation system.
Causes the system to beep when the LKAS is suspended.
ON/OFF*1
ON/OFF*1
*1: Default Setting
* Not available on all models
Continued
uuGauges and Driver Information InterfaceuDriver Information Interface
Setup Group Customizable Features Description Selectable Settings
|
Meter Setup |
Language Selection |
Changes the displayed language. |
English*1/Français/Español |
|
Adjust Outside Temp. Display |
Adjusts the temperature reading by a few degrees. |
-5°F ~ ±0°F*1 ~ +5°F (U.S.) -3°C ~ ±0°C*1 ~ +3°C (Canada) |
|
|
“Trip A” Reset Timing |
Changes the setting of how the distance, average fuel economy, average speed, and elapsed time of trip A is reset. |
When Refueled/IGN OFF/ Manually Reset*1 |
|
|
“Trip B” Reset Timing |
Changes the setting of how the distance, average fuel economy, average speed, and elapsed time of trip B is reset. |
When Refueled/IGN OFF/ Manually Reset*1 |
|
|
Adjust Alarm Volume |
Changes the volume setting for buzzers, warnings, turn signals, and other alerting systems. |
High/Mid*1/Low |
|
|
Fuel Efficiency Backlight |
Turns the ambient meter feature on and off. |
ON*1/OFF |
|
|
Speed/Distance Units |
Selects the trip computer units. |
mph∙miles*1/km/h∙km (U.S.) mph∙miles/km/h∙km*1 (Canada) |
|
|
Tachometer |
Selects whether the tachometer comes on the driver information interface. |
ON*1/OFF |
*1: Default Setting
uuGauges and Driver Information Interface uDriver Information Interface
Setup Group Customizable Features Description Selectable Settings
Headlight Auto OFF Timer
Changes the length of time the interior lights stay on after you close the doors.
Changes the length of time the exterior lights stay on after you close the driver’s door.
60sec/30sec*1/15sec
60sec/30sec/15sec*1/0sec
Auto Light Sensitivity* Changes the timing for the headlights to come on. Max/High/Mid*1/Low/Min
Auto Interior Illumination Sensitivity*
Auto Headlight ON With Wiper ON*
Changes the sensitivity of the brightness of the instrument panel when the headlight switch is in the AUTO position.
Changes the settings for the wiper operation when the headlights automatically come on while the headlight switch is in the AUTO position.
Max/High/Mid*1/Low/Min
ON*1/OFF
*1: Default Setting
* Not available on all models
Continued
uuGauges and Driver Information InterfaceuDriver Information Interface
Setup Group Customizable Features Description Selectable Settings
|
Door Setup |
Auto Door Lock |
Changes the setting for when the doors automatically lock. |
With Vehicle Speed*1/Shift From P*2/OFF |
|
Auto Door Unlock |
Changes the setting for when the doors automatically unlock. |
When Driver’s Door Opens*1/ When Shifting Into Park*2/ When Ignition Switched OFF/OFF |
|
|
Key And Remote Unlock Mode |
Sets up either the driver’s door or all doors to unlock on the first operation of the remote or ignition key. |
Driver Door*1/ All Doors |
|
|
Keyless Lock Answer Back |
LOCK/UNLOCK- The exterior lights flash. LOCK (2nd push)- The beeper sounds. |
ON*1/OFF |
|
|
Security Relock Timer |
Changes the time it takes for the doors to relock and the security system to set after you unlock the vehicle without opening a door. |
90sec/60sec/30sec*1 |
Resets or cancels the engine oil life display when you have performed the maintenance service.
*1: Default Setting
*2: Continuously variable transmission models
uuGauges and Driver Information Interface uDriver Information Interface
Below are steps that explain how to change the reset timing for trip A from the default setting (manual) so that it resets automatically when the vehicle is fully refueled.
Settings, then press the ENTER button.
appears on the display.
u Language Selection appears first in the display.
Continued
uuGauges and Driver Information InterfaceuDriver Information Interface
u The display switches to the customization setup screen, where you can select When Refueled, IGN OFF, Manually Reset, or Exit.
appears, then the display returns to the customization menu screen.
Controls
This chapter explains how to operate the various controls necessary for driving.
Clock 134
Locking and Unlocking the Doors
Key Types and Functions 136
Low Smart Entry Remote Signal Strength* 138
Locking/Unlocking the Doors from the Outside 139
Locking/Unlocking the Doors from the Inside 146
Childproof Door Locks 148
Auto Door Locking/Unlocking 149
Opening and Closing the Trunk 150
Security System
Immobilizer System 153
Security System Alarm 153
Opening and Closing the Windows 156
Moonroof* 159
* Not available on all models
Operating the Switches Around the Steering Wheel
Ignition Switch* 160
ENGINE START/STOP Button* 161
Ignition Switch and Power Mode Comparison 164
Turn Signals 165
Light Switches 166
Fog Lights* 169
Daytime Running Lights 169
Auto High-Beam* 170
Wipers and Washers 173
Brightness Control 175
Rear Defogger/Heated Door Mirror*
Button 176
Adjusting the Steering Wheel 177
Adjusting the Mirrors
Interior Rearview Mirror 178
Power Door Mirrors 179
Adjusting the Seats 180
Interior Lights/Interior Convenience Items 188
Heating System*
Using Automatic Heating 201
Automatic Heating Sensors 203
Climate Control System*
Using Automatic Climate Control 204
Automatic Climate Control Sensors 211
133
