2020 RAM 2500 Owners Manual - UCONNECT SETTINGS

Setting Name

Selectable Options

Display Mode

Auto

Manual

Set Language

English, Français, Español

Touchscreen Beep

On

Off

Fuel Saver Display

On

Off

NOTE:

The “Fuel Saver Display” feature will allow you to enable fuel saver mode and will be displayed in the instrument cluster display.

Setting Name

Selectable Options

Units

US

Metric

Custom

Speed

MPH

km/h

Distance

mi

km

Setting Name

Selectable Options

Fuel Consumption

MPG (UG)

MPG (UK)

L/100 km

km/L

Pressure

psi

kPa

bar

Power — If Equipped

HP (US)

HP (UK)

Kw

Temperature

°C

°F

Torque — If Equipped

lb-ft

Nm

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Always

With Help

Never

Setting Name

Selectable Options

Forward Collision Warning — If Equipped

Off

Warning Only

Warning & Braking

Forward Collision Warning Sensitivity — If Equipped

Near

Med

Far

Lane Sense Warning — If Equipped

Early

Med

Late

Lane Sense Strength — If Equipped

Low

Med

High

Front ParkSense Chime Volume - If Equipped

Low

Med

High

Rear ParkSense Chime Volume — If Equipped

Low

Med

High

Tilt Side Mirrors In Reverse — If Equipped

On

Off

NOTE:

When the “Tilt Side Mirrors In Reverse” feature is selected, the exterior side-view mirrors tilt downward when the ignition is in the ON/RUN position and the transmission gear selector is in the REVERSE position. The mirrors move back to their previous position when the transmission is shifted out of REVERSE.

Surround View Camera — If Equipped

On

Off

NOTE:

The “Surround View Camera” feature displays a complete 360 degree view of the vehicle's exterior environment while backing up.

Setting Name

Selectable Options

Forward Facing Camera Guidelines

— If Equipped

On

Off

NOTE:

The “Forward Facing Camera Guidelines” feature is an off-road type of feature that shows the path of the tires based on the steering wheel input.

CHMSL (Center High Mounted Stop Lamp) Camera Dynamic Centerline

— If Equipped

On

Off

NOTE:

When the “CHMSL Camera Dynamic Centerline” feature is selected, it will assist in backing up for trailer alignment and hook up. This feature is only available if your vehicle is equipped with Surround View Camera.

Rain Sensing Auto Wipers — If Equipped

On

Off

NOTE:

When the “Rain Sensing Auto Wipers” feature is selected, the system automatically activates the windshield wipers if it senses moisture on the wind- shield.

Hill Start Assist — If Equipped

On

Off

NOTE:

When the “Hill Start Assist” feature is selected, the Hill Start Assist (HSA) system becomes active.

Tire Fill Assist

On

Off

Setting Name

Selectable Options

Auto Door Locks — If Equipped

On

Off

NOTE:

When the “Auto Door Locks” feature is selected, all doors lock automatically when the vehicle reaches a speed of 15 mph (24 km/h).

Auto Unlock On Exit

On

Off

NOTE:

When the “Auto Unlock On Exit” feature is selected, all doors unlock when the vehicle is stopped, the transmission is in the PARK or NEUTRAL position and the driver's door is opened.

Sound Horn With Lock

Off

1st Press

2nd Press

Remote Door Unlock

All

Driver

NOTE:

The “Remote Door Unlock” feature allows you to program your remote door locks to open “All doors” or only the “Driver door” with the first push of the key fob or grabbing the Passive Entry door handle.

Sound Horn With Remote Start

On

Off

NOTE:

When the “Sound Horn With Remote Start” feature is selected, the horn sounds when the remote start is activated.

Memory Linked To Fob — If Equipped

On

Off

NOTE:

Setting Name

Selectable Options

Passive Entry — If Equipped

On

Off

NOTE:

The “Passive Entry” feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock buttons. It automat- ically unlocks the doors when the outside door handle is grabbed.

Flash Lights With Lock

On

Off

NOTE:

When the “Flash Lights With Lock” feature is selected, the exterior lights flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the “Sound Horn With Lock” feature selected.

Setting Name

Selectable Options

Power Side Steps

Automatic

Stow

Setting Name

Selectable Options

NOTE:

When the “Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start” feature is selected, the driver's heated seat and heated steering wheel will automatically turn on when temperatures are below 40°F (4.4°C). When temperatures are above 80°F (26.7°C), the driver vented seat will turn on.

Setting Name

Selectable Options

Easy Exit Seats — If Equipped

On

Off

Headlight Off Delay

0 sec

30 sec

60 sec

90 sec

Engine Off Power Delay

0 sec

45 sec

5 min

10 min

Setting Name

Selectable Options

Auto Entry/Exit — If Equipped

On

Off

Setting Name

Selectable Options

Display Suspension Messages

All

Warning Only

Tire Jack Mode

On

Off

Setting Name

Selectable Options

NOTE:

When this feature is selected, the air suspension system is disabled to prevent auto leveling of the suspension, while the vehicle is on a jack changing a tire.

Transport Mode

On

Off

NOTE:

When the “Transport Mode” feature is selected, the air suspension system is disabled to assist with flat bed towing.

Wheel Alignment Mode

On

Off

NOTE:

The “Wheel Alignment Mode” feature prevents auto leveling of the air suspension while performing a wheel alignment service. Before performing a wheel alignment, this mode must be enabled. Refer to an authorized dealer for further information.

Setting Name

Selectable Options

Balance/Fade

Front

Back

Left

Right

NOTE:

The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the Speaker icon or use the arrows to adjust, tap the C icon to readjust to the center.

Equalizer

+

–

NOTE:

When in the “Equalizer” display you may adjust the Bass, Mid and Treble settings.

Speed Adjusted Volume

Off

1

2

3

NOTE:

The “Speed Adjusted Volume” feature increases or decreases volume relative to vehicle speed.

Surround Sound — If Equipped

On

Off

NOTE:

The “Surround Sound” feature provides simulated surround sound mode.

AUX Volume Offset — If Equipped

On

Off

NOTE:

The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input.

Loudness — If Equipped

On

Off

NOTE:

The “Loudness” feature improves sound quality at lower volumes.

Setting Name

Selectable Options

Paired Phones

List of Paired Phones

NOTE:

The “Paired Phones” feature shows which phones are paired to the Phone/Bluetooth® system. For further information, refer to “Phone Operation” in “Uconnect 3 with 5-inch Display” section for further details.

Setting Name

Selectable Options

Restore Default Settings

Yes

Cancel

NOTE:

When the “Restore Default Settings” feature is selected it will reset the Display, Clock, Audio, and Radio Settings to their default settings. If “Yes” is selected a pop-up will appear asking "Are you sure you want to reset your settings to default?” select “Yes” to restore, or “Cancel” to exit.

Setting Name

Selectable Options

Clear Personal Data

Yes

Cancel

NOTE:

When this feature is selected it will remove all personal data including Bluetooth® devices and presets. If “Yes” is selected a pop-up will appear asking "Are you sure you want to clear all personal data?” select “Yes” to Clear, or “Cancel” to exit.

Setting Name

Selectable Options

Set Language

English

Français

Español

NOTE:

When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the Set Language button on the touchscreen, then press the desired language button on the touchscreen until a check-mark appears next to the language, showing that setting has been selected.

Setting Name

Selectable Options

Display Mode

Auto

Manual

NOTE:

When Auto or Manual is selected for the Display Mode, the usage of the Parade Mode feature will cause the radio to activate the Display Brightness Day control even though the headlights are on.

Display Brightness With Headlights ON

–

+

NOTE:

To make changes to the "Display Brightness With Headlights ON" setting, the headlights must be on and the interior dimmer switch must not be in the "party" or "parade" position.

Display Brightness With Headlights OFF

–

+

NOTE:

To make changes to the "Display Brightness With Headlights OFF" setting, the headlights must be off and the interior dimmer switch must not be in the "party" or "parade" position.

Touchscreen Beep

On

Off

Controls Screen Time-Out — If Equipped

On

Off

Fuel Saver Display in Cluster — If Equipped

On

Off

NOTE:

When selected, the system displays fuel saver mode in the instrument cluster.

Navigation Next Turn Pop-ups Displayed In Cluster — If Equipped

On

Off

Phone Pop-ups Displayed in Cluster — If Equipped

On

Off

Setting Name

Selectable Options

Units

US

Metric

Custom

NOTE:

When the “Custom” setting is selected, units will appear according to your personally configured settings. To configure these settings, press the Custom bar. The following settings will appear:

Speed

MPH

km/h

Distance

mi

km

Fuel Consumption

MPG (US)

MPG (UK)

L/100 km

km/L

Pressure

psi

kPa

bar

Power — If Equipped

HP (US)

HP (UK)

Kw

Temperature

°F

°C

Torque — If Equipped

lb-ft

Nm

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Never

w/Help

Always

Setting Name

Selectable Options

Sync Time With GPS — If Equipped

On

Off

Set Time Hours

–

+

Set Time Minutes

–

+

Time Format

12 hrs

24 hrs

AM

PM

Show Time In Status Bar — If Equipped

On

Off

NOTE:

The “Show Time In Status Bar” feature allows you to turn on or shut off the digital clock in the status bar.

Setting Name

Selectable Options

Surround View Camera — If Equipped

On

Off

NOTE:

The “Surround View Camera” feature displays a complete 360 degree view of the vehicle's exterior environment while backing up.

Surround View Camera Delay — If Equipped

On

Off

NOTE:

The “Surround View Camera Delay” setting determines whether or not the screen will display the 360 degree view image with guidelines for up to 10 seconds after the vehicle is shifted out of REVERSE. This delay will be canceled if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to the OFF position.

Setting Name

Selectable Options

NOTE:

When the “CHMSL Camera Dynamic Centerline” feature is selected, it will assist in backing up for trailer alignment and hook up. This feature is only available if your vehicle is equipped with Surround View Camera.

Setting Name

Selectable Options

Surround View Camera — If Equipped

On

Off

NOTE:

The “Surround View Camera” feature displays a complete 360 degree view of the vehicle's exterior environment while backing up.

Surround View Camera Delay — If Equipped

On

Off

NOTE:

The “Surround View Camera Delay” setting determines whether or not the screen will display the 360 degree view image with guidelines for up to 10 seconds after the vehicle is shifted out of REVERSE. This delay will be canceled if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to the OFF position.

Surround View Camera Guidelines

— If Equipped

On

Off

NOTE:

The “Surround View Camera Guidelines” feature allows you to see active guidelines over the Surround View camera display whenever the gear selector is put into REVERSE, or the Surround View button on the touchscreen is pressed. The image will be displayed on the radio touchscreen display.

Setting Name

Selectable Options

Forward Collision Warning — If Equipped

Off

Warning Only

Warning & Braking

NOTE:

Sounds an audible warning for the driver to slow the vehicle in case of collision or sounds an audible warning and appliesbrakes.

Forward Collision Warning Sensitivity — If Equipped

Near

Med

Far

NOTE:

Sets the distance in which a Forward Collision Warning occurs.

Front ParkSense Volume — If Equipped

Low

Med

High

Rear ParkSense Volume — If Equipped

Low

Med

High

Power Side Steps — If Equipped

Auto

Store

Blind Spot Alert — If Equipped

Off

Lights

Lights & Chime

Hill Start Assist — If Equipped

On

Off

Tire Fill Assist — If Equipped

On

Off

Setting Name

Selectable Options

Tilt Side Mirrors In Reverse — If Equipped

On

Off

Setting Name

Selectable Options

NOTE:

When the “Tilt Side Mirrors In Reverse” feature is selected, the outside side-view mirrors will tilt downward when the ignition is in the ON/RUN position and the transmission gear selector is in the REVERSE position. The mirrors will move back to their previous position when the transmission is shifted out of REVERSE.

Rain Sensing Auto Wipers — If Equipped

On

Off

NOTE:

Automatically adjusts the wiper speed based on the amount of precipitation.

Headlights with Wipers

On

Off

Setting Name

Selectable Options

NOTE:

When the “Headlights With Wipers” feature is selected, and the headlight switch is in the AUTO position, the headlights turn on approximately 10 seconds after the wipers are turned on. The headlights also turn off when the wipers are turned off if they were turned on by this feature.

Auto Dim High Beams — If Equipped

On

Off

NOTE:

When the “Auto Dim High Beams” feature is selected, the high beam headlights deactivate automatically under certain conditions.

Daytime Running Lights — If Equipped

On

Off

NOTE:

When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. This feature is only available if allowed by law in the country of the vehicle purchase.

Flash Lights With Lock

On

Off

NOTE:

When the “Flash Lights With Lock” feature is selected, the exterior lamps flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the Sound Horn On Lock feature selected.

Rear Cargo Guidance Lights — If Equipped

On

Off

NOTE:

When the “Rear Cargo Guidance Lights” feature is selected, the lights in the cargo and bed of the truck will come on either when the headlight switch is pressed, or the button on the back bed of the truck is pressed.

Setting Name

Selectable Options

Auto Door Locks — If Equipped

On

Off

NOTE:

When the “Auto Door Locks” feature is selected, all doors lock automatically when the vehicle reaches a speed of 15 mph (24 km/h).

Auto Unlock On Exit

On

Off

NOTE:

When the “Auto Unlock On Exit” feature is selected, all doors unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL position, and the driver's door is opened.

Flash Lights With Lock

On

Off

NOTE:

When the “Flash Lights With Lock” feature is selected, the front and rear turn signals flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the “Sound Horn With Lock” feature selected.

Sound Horn With Lock

Off

1st Press

2nd Press

Sound Horn With Remote Start

On

Off

1st Press Of Key Fob Unlocks

Driver Door

All Doors

Setting Name

Selectable Options

NOTE:

Passive Entry — If Equipped

On

Off

NOTE:

The “Passive Entry” feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob Lock or Unlock buttons.

Personal Settings Linked To Key Fob — If Equipped

On

Off

NOTE:

Setting Name

Selectable Options

Power Side Steps

Automatic

Stow

Setting Name

Selectable Options

Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start — If Equipped

Off

Remote Start

All Starts

NOTE:

When the “Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start” feature is selected, the driver's heated seat and heated steering wheel will automatically turn on when temperatures are below 40°F (4.4°C). When temperatures are above 80°F (26.7°C), the driver vented seat will turn on.

Setting Name

Selectable Options

Headlight Off Delay

–

+

NOTE:

When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle.

Setting Name

Selectable Options

Auto Entry/Exit — If Equipped

On

Off

Easy Exit Seat — If Equipped

On

Off

NOTE:

When the “Easy Exit Seat” feature is selected, the Driver’s seat will automatically move rearward once the engine is shut off.

Setting Name

Selectable Options

Display Suspension Messages

All

Warnings Only

Tire Jack Mode

On

Off

NOTE:

When the “Tire Jack Mode” feature is selected, the air suspension system is disabled to assist with changing a spare tire.

Transport Mode

On

Off

NOTE:

When the “Transport Mode” feature is selected, the air suspension system lowers and then disables to assist with flat bed towing.

Setting Name

Selectable Options

Wheel Alignment Mode

On

Off

NOTE:

Before performing a wheel alignment, the “Wheel Alignment Mode” must be enabled. Refer to an authorized dealer for further information.

Setting Name

Selectable Options

Trailer

Trailer 1

Trailer 2

Trailer 3

Trailer 4

Setting Name

Selectable Options

NOTE:

After pressing Next, the Tire Pressure screen appears. The default for this option is 50 PSI (344 kPa), however the range is selectable anywhere between 25–125 PSI (172–862 kPa). Once PSI (kPa) is programmed, the pairing screen appears. Tire sensors must be paired in order shown. Starting with Tire 1, deflate tire by 5 PSI (34 kPa) and wait for a horn chirp. Repeat process until complete. Do not exit the pairing screen until process is complete. If pairing has been unsuccessful, a double horn chirp will sound, and a prompt on the touchscreen will allow you to retry the procedure; “Retry” will only appear when setup fails. Each tire must be successfully paired during a single pairing process to receive the success screen.

Trailer Name

List of Trailer Names

NOTE:

You can select and personalize your trailer name depending on the type of trailer you are hauling. Select the trailer name from the following list: trailer, boat, car, cargo, dump, equipment, flatbed, gooseneck, horse, livestock, motorcycle, snowmobile, travel, utility, and 5th wheel.

Setting Name

Selectable Options

Balance/Fade

Front

Rear

Left

Right

NOTE:

The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the Speaker icon or use the arrows to adjust, tap the C icon to readjust to the center.

Equalizer

+

–

NOTE:

When in the “Equalizer” display, you may adjust the Bass, Mid and Treble settings.

Setting Name

Selectable Options

Speed Adjusted Volume

Off

1

2

3

NOTE:

The “Speed Adjusted Volume” feature increases or decreases volume relative to vehicle speed.

Surround Sound — If Equipped

On

Off

NOTE:

The “Surround Sound” feature provides simulated surround sound mode.

AUX Volume Offset — If Equipped

On

Off

NOTE:

The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input.

Auto Play

On

Off

Setting Name

Selectable Options

Paired Phones and Audio Devices

List Of Paired Phones and Audio Sources

NOTE:

The “Paired Phones and Audio Devices” feature shows which phones and audio sources are paired to the Phone and Audio Sources Settings system. For further information, refer to the Uconnect Owner’s Manual Supplement.

Smartphone Projection Manager

On

Off

Setting Name

Selectable Options

Tune Start

On

Off

NOTE:

The “Tune Start” feature begins playing the current song from the beginning when you tune to a music channel using one of the 12 presets, so you can enjoy the complete song. This feature occurs the first time the preset is selected during that current song. Tune Start works in the background, so you will not even realize it's on, except that you will miss the experience of joining your favorite song with only a few seconds left to play.

Channel Skip

List of Channels

NOTE:

SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scanning. This feature allows you to select the channels you would like to skip.

Setting Name

Selectable Options

Subscription Info

Sirius ID

NOTE:

New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM® Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.

SiriusXM® Travel Link is a separate subscription.

Setting Name

Selectable Options

Restore Default Settings

Yes

Cancel

NOTE:

When the “Restore Settings” feature is selected, it resets clock, audio and other features to their default settings.

Setting Name

Selectable Options

Clear Personal Data

Yes

Cancel

NOTE:

When this feature is selected it will remove all personal data including Bluetooth® devices and presets. If “Yes” is selected a pop-up will appear asking "Are you sure you want to clear all personal data?” select “Yes” to Clear, or “Cancel” to exit.

Setting Name

Selectable Options

Software License

System Software Information Screen

NOTE:

When the “Software License” feature is selected, a “System Software Information” screen will appear, displaying the system software version.

Setting Name

Selectable Options

Language

English

Español

Français

NOTE:

When the Language feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the Language button on the touchscreen, then press the desired language button on the touchscreen until a check-mark appears next to the language, showing that setting has been selected.

Setting Name

Selectable Options

Display Brightness Mode

Auto

Manual

NOTE:

Select Auto or Manual display mode and this allows adjustment of overall screen brightness.

Display Brightness Headlight ON

-

+

NOTE:

To make changes to the "Display Brightness With Headlights ON" setting, the headlights must be on and the interior dimmer switch must not be in the "party" or "parade" position.

Display Brightness Headlight OFF

-

+

NOTE:

To make changes to the "Display Brightness With Headlights OFF" setting, the headlights must be off and the interior dimmer switch must not be in the "party" or "parade" position.

Setting Name

Selectable Options

Set Theme

Pre-configured Themes

Touchscreen Beep

On

Off

Controls Screen Timeout — If Equipped

On

Off

Fuel Saver Display — If Equipped

On

Off

NOTE:

When selected, the system displays fuel saver mode in the instrument cluster.

Navigation Turn-by-Turn Displayed in Cluster — If Equipped

On

Off

Phone Pop-ups Displays In Cluster

On

Off

Ready To Drive Pop-Ups — If Equipped

On

Off

Setting Name

Selectable Options

Power — If Equipped

HP (US)

HP (UK)

Kw

Temperature

°F

°C

Torque — If Equipped

lb-ft

Nm

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Never

w/Help

Always

Setting Name

Selectable Options

Sync Time With GPS — If Equipped

On

Off

Set Time Hours

+

–

Set Time Minutes

+

–

Set Time Format

AM

PM

12 hrs

24 hrs

Show Time in Status Bar — If Equipped

On

Off

Setting Name

Selectable Options

Parkview Camera Delay — If Equipped

On

Off

NOTE:

The “Parkview Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to

10 seconds after the vehicle is shifted out of REVERSE. This delay will be canceled if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to the OFF position.

Active Backup Camera Guidelines — If Equipped

On

Off

NOTE:

The “Active Backup Camera Guidelines” feature overlays the Rear Backup Camera image with active or dynamic grid lines to help illustrate the width of the vehicle, and its projected backup path, based on the steering wheel position when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist with parking or aligning to a hitch/receiver.

Fixed Backup Camera Guidelines — If Equipped

On

Off

Forward Facing Camera Guidelines — If Equipped

On

Off

NOTE:

The “Forward Facing Camera Guidelines” feature is an off-road type of feature that shows the path of the tires based on the steering wheel input.

CHMSL (Center High Mounted Stop Lamp) Camera Dynamic Centerline — If Equipped

On

Off

NOTE:

When the “CHMSL Camera Dynamic Centerline” feature is selected, it will assist in backing up for trailer alignment and hook up. This feature is only available if your vehicle is equipped with Surround View Camera.

Cargo Camera Dynamic Centerline — If Equipped

On

Off

Setting Name

Selectable Options

Tilt Side Mirrors In Reverse — If Equipped

On

Off

NOTE:

When the “Tilt Side Mirrors In Reverse” feature is selected, the outside side-view mirrors will tilt downward when the ignition is in the ON/RUN position and the transmission gear selector is in the REVERSE position. The mirrors will move back to their previous position when the transmission is shifted out of REVERSE.

Rain Sensing Auto Wipers

On

Off

NOTE:

Automatically adjusts the wiper speed based on the amount of precipitation.

Headlights with Wipers

On

Off

Setting Name

Selectable Options

Headlight Off Delay

-

+

NOTE:

When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle.

Headlight Illumination On Approach

–

+

NOTE:

When the “Headlight Illumination On Approach” feature is selected, the headlights will activate and remain on for 0, 30, 60, or 90 seconds when the doors are unlocked with the key fob.

Setting Name

Selectable Options

Auto Door Locks

On

Off

Auto Unlock On Exit

On

Off

NOTE:

When the “Auto Unlock On Exit” feature is selected, all doors unlock when the vehicle is stopped, the transmission is in the PARK or NEUTRAL position, and the driver's door is opened.

Flash Lights With Lock

On

Off

NOTE:

When the “Flash Lights With Lock” feature is selected, the front and rear turn signals flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the “Sound Horn With Lock” feature selected.

Sound Horn with Lock — If Equipped

Off

1st Press

2nd Press

Sound Horn With Remote Start

On

Off

1st Press Of Key Fob Unlocks

Driver Door

All Doors

Setting Name

Selectable Options

Auto-On Driver Heated/Vented Seat & Steering Wheel — If Equipped

Off

Remote Start

All Starts

NOTE:

When the “Auto-On Driver Heated/Vented Seat & Steering Wheel” feature is selected, the driver's heated seat and heated steering wheel will auto- matically turn on when temperatures are below 40°F (4.4°C). When temperatures are above 80°F (26.7°C), the driver vented seat will turn on.

Setting Name

Selectable Options

Engine Off Power Delay

+

–

NOTE:

When the “Engine Off Power Delay” feature is selected, the power window switches, radio, Uconnect phone system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 10 minutes after the ignition is cycled to OFF. Opening either front door will cancel this feature.

Headlight Off Delay

+

–

NOTE:

When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle.

Setting Name

Selectable Options

Auto Entry/Exit — If Equipped

On

Off

Easy Exit Seat — If Equipped

On

Off

NOTE:

When the “Easy Exit Seat” feature is selected, the Driver’s seat will automatically move rearward once the engine is shut off.

Setting Name

Selectable Options

Trailer

Trailer 1

Trailer 2

Trailer 3

Trailer 4

Setting Name

Selectable Options

Use This Trailer

On

Off

Braking

Light Electric

Light Electric Over Hydraulic

Heavy Electric

Heavy Electric Over Hydraulic

Tire Pressure

Are you sure you want to delete the Tire Pressure Settings for Trailer 1?

Yes

No

Number Of Axles

+

-

Number Of Tires

+

-

NOTE:

After pressing Next, the Tire Pressure screen appears. The default for this option is 50 PSI (344 kPa), however the range is selectable anywhere between 25–125 PSI (172–862 kPa). Once PSI (kPa) is programmed the pairing screen appears. Tire sensors must be paired in order shown. Starting with Tire 1, deflate tire by 5 PSI (34 kPa) and wait for a horn chirp. Repeat process until complete. Do not exit the pairing screen until process is complete. If pairing has been unsuccessful, a double horn chirp will sound, and a prompt on the touchscreen will allow you to retry the procedure; “Retry” will only appear when setup fails. Each tire must be successfully paired during a single pairing process to receive the success screen.

Setting Name

Selectable Options

Trailer Name

List of Trailer Names

NOTE:

You can select and personalize your trailer name depending on the type of trailer you are hauling. Select the trailer name from the following list: trailer, boat, car, cargo, dump, equipment, flatbed, gooseneck, horse, livestock, motorcycle, snowmobile, travel, utility, and 5th wheel.

Setting Name

Selectable Options

Surround Sound — If Equipped

On

Off

NOTE:

The “Surround Sound” feature provides simulated surround sound mode.

AUX Volume Offset — If Equipped

On

Off

NOTE:

The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input.

Auto Play

On

Off

Setting Name

Selectable Options

Phone Pop-ups Displayed in Cluster

On

Off

Do Not Disturb

List of Settings

NOTE:

Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (Both, Text, Call), Auto Reply Message (Custom, Default), and Custom Auto Reply Message (Create Message).

Paired Phones and Audio Devices

List Of Paired Phones and Audio Sources

NOTE:

The “Paired Phones and Audio Devices” feature shows which phones and audio sources are paired to the Phone and Audio Sources Settings system. For further information, refer to the Uconnect Owner’s Manual Supplement.

Setting Name

Selectable Options

Smartphone Device Mirroring — If Equipped

On

Off

Enable CarPlay Projections — If Equipped

On

Off

Automatically Display Pop-Ups in Cluster — If Equipped

On

Off

Set as Default Device — If Equipped

On

Off

Projection Manager

Smartphone Device Mirroring On

Smartphone Device Mirroring Off

Setting Name

Selectable Options

Sirius All Access

Choose a Subscription Package

Add Listener

Add up to five profiles

NOTE:

The “Add Listener” feature allows you to add up to five different profiles for customizing personal music or satellite radio choices.

Listener Items

Listening History

List Of Options

Tune Start

On

Off

NOTE:

The “Tune Start” feature begins playing the current song from the beginning when you tune to a music channel using one of the 12 presets, so you can enjoy the complete song. This feature occurs the first time the preset is selected during that current song. Tune Start works in the background, so you will not even realize it's on, except that you will miss the experience of joining your favorite song with only a few seconds left to play.

Channel Skip

List of Channels

Setting Name

Selectable Options

NOTE:

SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scanning. This feature allows you to select the channels you would like to skip.

Subscription Info

Sirius ID

NOTE:

New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM® Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.

SiriusXM® Travel Link is a separate subscription.

Setting Name

Selectable Options

Reset App Drawer to Default Order

Yes

Cancel

Restore Settings

Yes

Cancel

NOTE:

When the “Restore Settings” feature is selected, it resets all settings to their default settings.

Setting Name

Selectable Options

Clear Personal Data

Yes

Cancel

NOTE:

When the “Clear Personal Data” feature is selected it removes all personal data including Bluetooth® devices and presets.

Setting Name

Selectable Options

Clear SiriusXM® Data

Done

NOTE:

You must contact SiriusXM® Customer Care at 1-855-290-6593 in order to remove your account and profile information associated with SiriusXM® in this vehicle.
